Why Choose PES Series for Your Off-Grid Energy Needs?
PowerLink’s PES Series delivers reliable, flexible, and sustainable hybrid energy storage solutions (BESS). It is purpose-built for industries operating beyond the reach of the traditional grid. Whether you are tackling remote off-grid challenges or require a robust backup power source, these systems perform under pressure.
The PES Series provides high-performance energy exactly where it’s needed most. In this guide, we’ll dive deep into the series to explore its core features, cost-saving benefits, and the technical specifications that set it apart from standard generators.
Key Features of the PES Series
1. Hybrid Energy Input
The PES series is designed to accept both solar power and diesel power inputs, giving users the flexibility to choose the best energy source for their needs. This hybrid energy input allows the system to operate efficiently in various environments, minimizing reliance on traditional power grids.
2. Modular and Scalable Design
One of the standout features of the PES series is its modular design. These systems come in multiple configurations, ranging from 30 kWe to 500 kWe, allowing them to scale according to the specific energy requirements of the application. This flexibility makes the PES series suitable for both small and large energy needs.
3. High Battery Capacity
PES units are equipped with substantial battery capacities, ranging from 62 kWh to 576 kWh, depending on the model. The large battery storage ensures continuous power supply, even when solar energy is not available, or during periods of high demand.
4. Flexible Power Inputs
In addition to solar power and diesel generators, the PES series can also integrate with the electrical grid, offering users even greater flexibility. This hybrid approach reduces fuel consumption, lower emissions, and saves on operational costs, making it a cost-effective solution for various applications.
5. Eco-Friendly and Cost-Effective
The integration of solar power and energy storage into the PES system allows it to operate with minimal reliance on fossil fuels. As a result, users can reduce their carbon footprint while lowering operational costs. The system’s hybrid nature maximizes the use of renewable energy, significantly reducing fuel consumption and greenhouse gas emissions.
6. Portability and Compact Design
The PES series is compact and portable, designed to be easily transported and deployed in various settings. These systems are suitable for temporary or mobile power requirements, such as in construction sites, events, or remote mining operations.
Applications of the PES Series
1. Construction Sites
The PES system is ideal for providing off-grid power to construction sites, especially those in remote locations where connecting to the main grid is not feasible. The system can power machinery, tools, lighting, and other equipment, ensuring that projects run smoothly and on schedule.
2. Mining Operations
Mining sites often operate in harsh and isolated environments, where traditional power grids are unavailable. The PES series provides a reliable power source for mining operations, ensuring that critical equipment, such as drills and pumps, can operate without interruption.
3. Events and Festivals
Large-scale events such as concerts, festivals, and exhibitions require significant power to operate lighting, sound systems, and other equipment. The PES system can provide a reliable and uninterrupted power supply, regardless of the event’s location, ensuring that everything runs smoothly.
4. Port Operations
Ports need reliable power for cranes, lighting, and other equipment. The PES series offers an efficient, off-grid solution that reduces downtime and ensures continuous operation in areas where access to the main power grid is limited or unavailable.
5. Emergency Power Supply
In the event of a natural disaster or power grid failure, the PES series can provide immediate backup power to critical infrastructure such as hospitals, shelters, and emergency response centers. Its portable design makes it an excellent solution for rapid deployment in emergency situations.
Technical Specifications of the PES Series
The PES series is available in several models, each with its own set of specifications to cater to different power needs. Below are the technical details for each model:
| Specification | PES30 | PES60 | PES100 | PES200 | PES300 | PES400 | PES500 |
| Output Power (kWe) | 30 | 60 | 100 | 200 | 300 | 400 | 500 |
| Output Voltage (V) | 400/415 | 400/415 | 400/415 | 400/415 | 400/415 | 400/415 | 400/415 |
| Battery Capacity (kWh) | 62 | 92 | 115 | 230 | 346 | 461 | 576 |
| PV Input (kWp) | 30 | 60 | 60 | 60 | 110 | 110 | 110 |
| AC Charge (kW) | 30 | 30 | 30 | 2×30 | 3×30 | 4×20 | 5×16 |
| 40′ Loading (qty) | 14 | 7 | 4 | 2 | 1 | 1 | 1 |
As shown, the PES series models vary in terms of output power, battery capacity, and PV input, making it easy to choose the right model based on specific needs. These systems are designed to be compact, with the dimensions and weight depending on the output power.
How PES Series Hybrid Energy Systems Operate?
The PES series system employs a hybrid energy model, integrating multiple energy sources such as solar, diesel, and the power grid. During the day, solar energy serves as the primary energy source, while the system’s batteries store excess energy for use at night or on cloudy days.
When solar energy is insufficient, the diesel generator can charge the batteries. Furthermore, the system can be connected to the grid as a backup power source or supplement renewable energy when needed.
This hybrid model ensures a continuous energy supply while reducing fuel consumption and emissions by optimizing the use of renewable energy. Ultimately, the system provides a more sustainable and cost-effective power supply solution for off-grid operation.
Benefits of the PES Series Hybrid Systems
1. Reduced Operational Costs
By incorporating renewable energy and reducing reliance on fossil fuels, the PES systems significantly lower operational costs. The hybrid nature of these systems allows for optimal energy use, reducing fuel consumption and maintenance costs associated with traditional diesel generators.
2. Increased Reliability
The PES series provides a stable and reliable power supply, even in remote or harsh environments. Its hybrid system ensures that energy is always available, reducing the risk of power outages that could disrupt operations.
3. Eco-Friendly
By using solar energy and minimizing the use of diesel, the PES series helps reduce greenhouse gas emissions. This makes it an eco-friendly option for industries looking to lower their carbon footprint while maintaining a reliable power supply.
4. Quick Deployment
The portable design of the PES systems makes them easy to transport and deploy, making them ideal for temporary or mobile power requirements. Whether for an event, construction site, or emergency response, the PES system can be quickly set up to provide immediate power.
Conclusion
PowerLink’s PES Series offers a reliable and eco-friendly solution for off-grid power. These portable hybrid systems are built to be cost-effective.
By combining solar and diesel power, the PES Series significantly slashes operating costs. It also lowers emissions while boosting overall energy security.
For industries prioritizing efficiency, the PES Series stands out. It delivers robust performance and a stable power supply. You can count on it even in remote or harsh environments.
The system is highly versatile. It is perfect for everything from temporary events to remote mining operations. Whatever the challenge, the PES Series provides the high performance needed to meet modern energy demands.
